KA Aircraft
|
KA Aircraft is developing a updated Ercoupe kit. This version is composite and called the Coupe Cruiser. This version will have a wider cockpit than the original Ercoupe, better wing loading, flaps, and will use engines from 118 - 125 horsepower for a cruise of 140.
|
Length
|
20 ft. 10 in.
|
Height
|
6 ft. 3 in.
|
Cabin Width
|
44 in.
|
Gross Weight
|
1550
|
Empty Weight
|
850 lbs.
|
Baggage
|
75 lbs.
|
Useful Load
|
700 lbs.
|
Fuel Capacity
|
32 US Gal.
30 Usable
|
Engine
|
IO-240
|
Engine HP
|
125
|
Power Loading
|
12.4 lbs/HP
|
|
|
|
Wing Span
|
28 ft
|
Wing Cord
|
57 in
|
Wing Area
|
130.6 sq. ft.
|
Wing Loading
|
11.8 lb/sq. ft.
|
Aspect Ratio
|
6
|
Aileron Area
|
8.4 sq. ft.
|
Flap Area
|
19.6 sq. ft.
|
|
Discussion Group: Yahoo! Coupe Cruiser Group
